#include <XInput.h>

// Setup
const boolean UseLeftJoystick   = true;  // set to true to enable left joystick
const boolean InvertLeftYAxis   = false;  // set to true to use inverted left joy Y


const boolean UseRightJoystick  = false;  // set to true to enable right joystick


const boolean UseTriggerButtons = true;   // set to false if using analog triggers

const int ADC_Max = 1023;  // 10 bit

// Joystick Pins
const int Pin_LeftJoyX  = A0;
const int Pin_LeftJoyY  = A1;


// Trigger Pins
const int Pin_TriggerL = A4;
const int Pin_TriggerR = A5;

// Button Pins
const int Pin_ButtonA = 0;
const int Pin_ButtonB = 1;
const int Pin_ButtonX = 2;
const int Pin_ButtonY = 3;

const int Pin_ButtonLB = 4;
const int Pin_ButtonRB = 5;

const int Pin_ButtonBack  = 6;
const int Pin_ButtonStart = 7;

// Directional Pad Pins
const int Pin_DpadUp    = 8;
const int Pin_DpadDown  = 9;
const int Pin_DpadLeft  = 10;
const int Pin_DpadRight = 11;

void setup() {
	// If using buttons for the triggers, use internal pull-up resistors
	if (UseTriggerButtons == true) {
		pinMode(Pin_TriggerL, INPUT_PULLUP);
		pinMode(Pin_TriggerR, INPUT_PULLUP);
	}
	// If using potentiometers for the triggers, set range
	else {
		XInput.setTriggerRange(0, ADC_Max);
	}

	// Set buttons as inputs, using internal pull-up resistors
	pinMode(Pin_ButtonA, INPUT_PULLUP);
	pinMode(Pin_ButtonB, INPUT_PULLUP);
	pinMode(Pin_ButtonX, INPUT_PULLUP);
	pinMode(Pin_ButtonY, INPUT_PULLUP);

  pinMode(Pin_ButtonLB, INPUT_PULLUP);
  pinMode(Pin_ButtonRB, INPUT_PULLUP);

  pinMode(Pin_ButtonBack, INPUT_PULLUP);
  pinMode(Pin_ButtonStart, INPUT_PULLUP);

	pinMode(Pin_DpadUp, INPUT_PULLUP);
	pinMode(Pin_DpadDown, INPUT_PULLUP);
	pinMode(Pin_DpadLeft, INPUT_PULLUP);
	pinMode(Pin_DpadRight, INPUT_PULLUP);

	XInput.setJoystickRange(0, ADC_Max);  // Set joystick range to the ADC
	XInput.setAutoSend(false);  // Wait for all controls before sending

	XInput.begin();
}

void loop() {
	// Read pin values and store in variables
	// (Note the "!" to invert the state, because LOW = pressed)
	boolean buttonA = !digitalRead(Pin_ButtonA);
	boolean buttonB = !digitalRead(Pin_ButtonB);
	boolean buttonX = !digitalRead(Pin_ButtonX);
	boolean buttonY = !digitalRead(Pin_ButtonY);

  boolean buttonLB = !digitalRead(Pin_ButtonLB);
  boolean buttonRB = !digitalRead(Pin_ButtonRB);

  boolean buttonBack  = !digitalRead(Pin_ButtonBack);
  boolean buttonStart = !digitalRead(Pin_ButtonStart);

	boolean dpadUp    = !digitalRead(Pin_DpadUp);
	boolean dpadDown  = !digitalRead(Pin_DpadDown);
	boolean dpadLeft  = !digitalRead(Pin_DpadLeft);
	boolean dpadRight = !digitalRead(Pin_DpadRight);

	// Set XInput buttons
	XInput.setButton(BUTTON_A, buttonA);
	XInput.setButton(BUTTON_B, buttonB);
	XInput.setButton(BUTTON_X, buttonX);
	XInput.setButton(BUTTON_Y, buttonY);

  XInput.setButton(BUTTON_LB, buttonLB);
  XInput.setButton(BUTTON_RB, buttonRB);

  XInput.setButton(BUTTON_BACK, buttonBack);
  XInput.setButton(BUTTON_START, buttonStart);


	// Set XInput DPAD values
	XInput.setDpad(dpadUp, dpadDown, dpadLeft, dpadRight);

	// Set XInput trigger values
	if (UseTriggerButtons == true) {
		// Read trigger buttons
		boolean triggerLeft  = !digitalRead(Pin_TriggerL);
		boolean triggerRight = !digitalRead(Pin_TriggerR);

		// Set the triggers as if they were buttons
		XInput.setButton(TRIGGER_LEFT, triggerLeft);
		XInput.setButton(TRIGGER_RIGHT, triggerRight);
	}
	else {
		// Read trigger potentiometer values
		int triggerLeft  = analogRead(Pin_TriggerL);
		int triggerRight = analogRead(Pin_TriggerR);

		// Set the trigger values as analog
		XInput.setTrigger(TRIGGER_LEFT, triggerLeft);
		XInput.setTrigger(TRIGGER_RIGHT, triggerRight);
	}

// Set left joystick
  if (UseLeftJoystick == true) {
    int leftJoyX = analogRead(Pin_LeftJoyX);
    int leftJoyY = analogRead(Pin_LeftJoyY);

    // White lie here... most generic joysticks are typically
    // inverted by default. If the "Invert" variable is false
    // then we'll take the opposite value with 'not' (!).
    boolean invert = !InvertLeftYAxis;

    XInput.setJoystickX(JOY_LEFT, leftJoyX);
    XInput.setJoystickY(JOY_LEFT, leftJoyY, invert);
  }



	// Send control data to the computer
	XInput.send();
}
